CIRCULAR SAW BLADES
G5 System Tungsten Carbide Grooving Saw Blade For HL Board 03
$281.74
● IN STOCK
Confused about compatibility?
Ask our AI Advisor about feed rates, machine compatibility, and custom applications for this tool.
Description
For chip-free grooving in solid woods, raw and laminated wood-based panels, and plastics the G5 has an ATB with alternating face shear which yields better cut quality. We call it a G5 for its repeating 5 tooth sequence: Right Left Right Left FLAT. This blade type is suitable for chip-free groove cuts in wood-based panels, solid woods, & plastics. The LEUCO HL Board 03 brings extremely long edge life, & noise-reduction thanks to highly wear-resistant cutting material.
VENDOR: LEUCO Circular Saw Blades
| Size / Variant | Price | SKU | Stock |
|---|---|---|---|
| CIR 100 x 5 x 4 x 30 Z=35 G5 | $281.74 | 191947 | In Stock |
| CIR 120 x 4 x 2.8 x 20 Z=35 G5 | $217.36 | 191948 | In Stock |
| CIR 120 x 5 x 4 x 20 Z=35 G5 | $280.84 | 191949 | In Stock |
| CIR 120 x 5 x 4 x 20 Z=35 2x3|4.5|35 G5 | $328.76 | 191951 | In Stock |
| CIR 120 x 5 x 4 x 35 Z=35 G5 | $349.23 | 191953 | In Stock |
| CIR 125 x 5 x 4 x 30 Z=35 G5 | $288.54 | 191946 | In Stock |
Specifications for SKU: 191947
| Diameter - Outermost cutting point [mm] | 100 |
| Bore / shank diameter [mm] | 30 |
| Cutting width 1 [mm] | 5 |
| Clamping length [mm] | 4 |
| Tooth configuration | G5 [G5] |
| Number of teeth | 35 |
| Number of teeth diameter [mm] | 35 |
| Interface towards the machine | Bore [BO] |
| Cutting material specification | HL Board 03 [B03] |
| Cutting material group | Tungsten carbide [HW] |
| Diameter max [mm] | 100 |
| Diameter [mm] | 100 |
| Cutting direction | Universal [UNI] |
| Type of feed | Mechanical feed [MEC] |
| Weight Kg | 0.27 |
| RPM max [min-1] | 19100 |
Application
- —for chip-free grooving in solid woods, raw and laminated wood-based panels and plastics
Machines
- —Weeke BHX series
- —CNC machining centers and aggregates
Design
- —tooth configuration: G5
- —cutting material: HW HL Board 03, HL Board 05
Advantages
- —excellent cutting qualtiy
- —especially low noise level
- —long edge lives also thanks to highly wear-resistant cutting material
