CIRCULAR SAW BLADES
G5 System Tungsten Carbide Grooving Saw Blade For HL Board 04
$209.19
● IN STOCK
Confused about compatibility?
Ask our AI Advisor about feed rates, machine compatibility, and custom applications for this tool.
Description
For chip-free grooving in solid woods, raw and laminated wood-based panels, and plastics the G5 has an ATB with alternating face shear which yields better cut quality. We call it a G5 for its repeating 5 tooth sequence: Right Left Right Left FLAT. This blade type is suitable for chip-free groove cuts in wood-based panels, solid woods, & plastics. The LEUCO HL Board 04 plus brings excellent cutting quality for cross cuts, extremely long edge life, & noise-reduction thanks to laser ornaments.
VENDOR: LEUCO Circular Saw Blades
| Size / Variant | Price | SKU | Stock |
|---|---|---|---|
| CIR 100 x 4 x 2.8 x 30 Z=35 G5 | $209.19 | 189994 | In Stock |
| CIR 120 x 4 x 2.8 x 35 Z=35 G5 | $267.02 | 191952 | In Stock |
| CIR 125 x 4 x 2.8 x 30 Z=35 G5 | $239.44 | 189993 | In Stock |
Specifications for SKU: 189994
| Diameter - Outermost cutting point [mm] | 100 |
| Bore / shank diameter [mm] | 30 |
| Cutting width 1 [mm] | 4 |
| Clamping length [mm] | 2.8 |
| Tooth configuration | G5 [G5] |
| Number of teeth | 35 |
| Number of teeth diameter [mm] | 35 |
| Cutting material specification | HL Board 04 [B04] |
| Cutting material group | Tungsten carbide [HW] |
| Diameter max [mm] | 100 |
| Diameter [mm] | 100 |
| Cutting direction | Universal [UNI] |
| Type of feed | Mechanical feed [MEC] |
| Weight Kg | 0.193 |
| RPM max [min-1] | 19100 |
| RPM min [min-1] | 19100 |
| Corner angle | 15 |
Application
- —for chip-free grooving in solid woods, raw and laminated wood-based panels and plastics
Machines
- —Weeke BHX series
- —CNC machining centers and aggregates
Design
- —tooth configuration: G5
- —cutting material: HW HL Board 03, HL Board 05
Advantages
- —excellent cutting qualtiy
- —especially low noise level
- —long edge lives also thanks to highly wear-resistant cutting material
