Solid Carbide Radius Profile Knives with 1 Cutting Radius and Bottom Chamfer for Edge Rounding Cutterheads For HLB 05
$191.38
● IN STOCK
Confused about compatibility?
Ask our AI Advisor about feed rates, machine compatibility, and custom applications for this tool.
Description
Set of 10 solid carbide with radius profile replacement knives with 1 cutting radius and bottom chamfer for edge rounding cutterheads when shaping for wood-based panels, plastics and hard wood materials.
VENDOR: LEUCO Knives and Inserts
| Size / Variant | Price | SKU | Stock |
|---|---|---|---|
| KNI 12 x 14.5 x 2 HLB 05 R=2 RH | $191.38 | 172141 | In Stock |
| KNI 12 x 14.5 x 2 HLB 05 R=2 LH | $191.38 | 172142 | In Stock |
| KNI 12 x 14.5 x 2 HLB 05 R=2.5 RH | $144.61 | 171223 | In Stock |
| KNI 12 x 14.5 x 2 HLB 05 R=2.5 LH | $187.16 | 171224 | In Stock |
| KNI 12 x 14.5 x 2 HLB 05 R=3 RH | $221.29 | 172143 | In Stock |
| KNI 12 x 14.5 x 2 HLB 05 R=3 LH | $194.83 | 172144 | In Stock |
Specifications for SKU: 172141
| Bore / shank diameter [mm] | 4 |
| Cutting width 1 [mm] | 12 |
| Thickness [mm] | 2 |
| Cutting material specification | HL Board 05 [B05] |
| Cutting material group | Tungsten carbide [HW] |
| Radius 1 | 2 |
| Cutting direction | Right-hand rotation [RH] |
| Height [mm] | 14.5 |
| Type | 2 |
| Wedge angle [°] | 55 |
Application
- —for use in edge rounding cutterheads
Design
- —cutting material: HW
- —HL Board 05 and HL Board 06 for wood-based panels, plastics and hard woods
