HomeKnives & InsertsSolid Carbide Radius Profile Knives with 1 Cutting Radius and Bottom Chamfer for Edge Rounding Cutterheads For HLB 06

KNIVES AND INSERTS
Solid Carbide Radius Profile Knives with 1 Cutting Radius and Bottom Chamfer for Edge Rounding Cutterheads For HLB 06
$439.45
Confused about compatibility?
Ask our AI Advisor about feed rates, machine compatibility, and custom applications for this tool.
Description
Set of 10 solid carbide with radius profile replacement knives with 1 cutting radius and bottom chamfer for edge rounding cutterheads when shaping for wood-based panels, plastics and hard wood materials.
VENDOR: LEUCO Knives and Inserts
| Size / Variant | Price | SKU | Stock |
|---|---|---|---|
| KNI 14.5 x 14.5 x 2 HLB 06 R=2 RH | $439.45 | 185376 | |
| KNI 14.5 x 14.5 x 2 HLB 06 R=2 LH | $439.45 | 185377 | |
| KNI 14.5 x 14.5 x 2 HLB 06 R=2.5 LH | $270.32 | 181657 | |
| KNI 14.5 x 14.5 x 2 HLB 06 R=2.5 RH | $270.32 | 181658 |
Specifications for SKU: 185376
| Bore / shank diameter [mm] | 5 |
| Cutting width 1 [mm] | 14.5 |
| Thickness [mm] | 2 |
| Cutting material specification | HL Board 06 [B06] |
| Cutting material group | Tungsten carbide [HW] |
| Radius 1 | 2 |
| Cutting direction | Right-hand rotation [RH] |
| Weight Kg | 0.02 |
| Height [mm] | 14.5 |
| Wedge angle [°] | 55 |
Application
- —for use in edge rounding cutterheads
Design
- —cutting material: HW
- —HL Board 05 and HL Board 06 for wood-based panels, plastics and hard woods
